Insulated sandwich panel production line for EPS a

Insulated Sandwich panel production line makes the color coated steel stick on both sides of core material, then forms a new building material with the character of high-intension,light-weight,heat-insulation,durable and elegant-appearance.Besides,its bright color makes it do not need secondary decoration.It has been widely applied on wall and roof of light steel structure buildings. The production line integrated with pneumatic electricity and engine, which is specialized in manufacturing colored steel heat insulation sandwich panel. This production line can produce and compound tile panel. The whole line is consisted of uncoiler, cutting machine, laminating system ( ribbon, gelatinizing, heating up, compounding, crimping, notching, edge trimmer, automatic cutting )and is computer operated, which is necessary to manufacture roof and wall panels for industrial workshop, warehouses,clean room and cold room. Technique parameters of the processing line (1) Coil material: PU Both sides: aluminum coil (2) Thickness of the plate : 0.3-0.8mm (3) Core thickness: 20-300mm (4) Production capacity(according to your glue ): 4-4.5m/min (the fastest) ,2-2.5m/min(the slowest) (5) Total power: about 30KW (6) Weight: 25ton (7) PLC control systerm, easy to operate, high precision and work stably. (8) Dimensions of whole production line: about Length34000mm × Width2500mm × Height2600mm Processes: Composite Decoiler—Roll Forming—Seaming--laminating system ( ribbon, gelatinizing, heating up, compounding, crimping, notching, edge trimmer)—cutting systerm—Runout Table
